u Unique positive electrode materials paired with special electrolytes, best fit the demand of application in high discharge capacity under high variation of temperature from -40 degree to +125 degree, such as automotive TPMS
Product Features
SIZE | <mm> |
Diameter | 20（0~-0.3） |
Height | 3.2（0~-0.3） |
Parameter | CR2032GW |
Nominal Capacity (mAh) | 245 |
Standard Voltage (V) | 3.0 |
Continuous Discharge Current (Maximum Discharge Utilization)(mA) | ≤1.0 |
Volume(mm3) | 1004.8 |
Net Weight (g) | 3.2 |
Operating Temperature(℃) | -40 ~ 125 |
Maximum Storage Temperature（℃） | 140 |
Acceleration Resistance（G） | Max.2000 |
Volume Energy Density (Wh/L) | 731.49 |
Mass Energy Density (Wh/kg) | 229.69 |
The above indicators are reference values for typical products of the company. If you need customization, please contact us.
